Nylon tube, PA6, PA11, PA12 tube, Polyamide tube

Home > Nylon tubes > Nylon tube


	PA6/PA11/PA12 tube Nylon tube PA12 PHL tube with high pressure. 100% new material with high quality. UBE, BASF, EMS, DUPONT material are avaiable. DIN 73378 standard

Samlongda natural-coloured and/or transparent plastic tube PA 12 PHL is printed black
and the black plastic tube PA 12HL is printed white.
As agreed, the plastic tube PA 12HL can also be delivered in such colours as green,
red, black, or brown.
On request, Samlongda can also offer our plastic tube PA 12HL to our customers
in other dimensions. Our wide flexibility becomes also apparent in case of enquiries as regards special lengths
such as e.g. a reel of 2,000 m. We can also meet such demands without any problem.

Samlongda produce air brake PA 12 tubing wtih China top brand resin supplier.

Other PA 6 tubing, PA 11 tubing are also available for OEM serivice.

Code	Size			Working Pressure(Bar)	Tolerances
Code	O.D(mm)	I.D(mm)	Length(M)	Working Pressure(Bar)	MM
PA060425	4	2.5	200	31.0	±0.10
PA060402	4	2	200	45.0	±0.10
PA060503	5	3	200	34.0	±0.10
PA060604	6	4	200	27.0	±0.10
PA060805	8	6	100	22.0	±0.10
PA061065	10	8	100	15.0	±0.15
PA061075	10	7.5	100	19.0	±0.12
PA061208	12	9	100	27.0	±0.15
PA061612	16	12	100	19.0	±0.15
