Nylon tubes, Pneumatic tubing, Polyamide tube, air brake tube. - PA 6 tubing
Nylon tubes, PA 6 tubing, PA tubing, PU tubing

PA 6 tubing

*100% virgin material.

*polished & shinny surface.

* flexible  than recycle than tubing.

*High pressure to 60bar.











Code Size(mm) W.P.(Mpa) B.P. (Mpa) Standard Length(m) Bend Radii (mm)
O.D I.D
P60302 3 2 2.5 2.8 100 18
P60425 4 2.5 2.7 4.2 100 20
P60402 4 2 3.2 6.0 100 30
P60503 5 3 2.3 4.8 100 35
P60604 6 4 3.1 6.2 100 40
P60806 8 6 2.5 4.5 100 50
P61008 10 8 2.6 4.8 100 65
P61075 10 7.5 2.5 4.5 100 65
P61209 12 9 2.5 4.5 100 70
P61612 16 12 1.8 3.6 100 80
